Medical Instrument PN-1691 (1*4) / Two-plates mold / Cold runner No.21063-B

Product Categories

Dongguan Chitwing Technologies Co., Ltd

Contact Now

Name: Medical Instrument PN1691 14 Twoplates mold Cold runner No21063B
Brand: Chitwing
Price: 1 USD

Brand Name : Chitwing

Model Number : Armamentarium

Certification : ISO 9001:2015

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 200 set/month

Delivery Time : 30 day(s)

Packaging Details : The mold is packaged with a wooden box and placed on a wood pallet.

Size : 250.000 X 250.000 X 261.000

Part weight : 0.11g

Design software : (3D)UG 4.0/ (2D）CAD

Mould life : ≥500000 shots

Gate : Side gate

Injection type : Cold runner

Runner type : Cold runner

Contact Now

Medical Instrument PN-1691 (1*4)

No.21063-B

Standard mold base P/N: CI2025.508070

Standard:LKM

The mold dimensions are 250x250x261mm, designed for a 100T injection molding machine,

with a net weight of 93 kg. It features two slides.

Medical Instrument PN-1691 (1*4) / Two-plates mold / Cold runner No.21063-B

The mold features side gate design and has a lifespan of over 500k shots.

It utilizes a cold runner system and the injection-molded part is made of PC+PET material.

The part has a net weight of 0.11g and dimensions of 10.22x6.70x10.20mm.

Medical Instrument PN-1691 (1*4) / Two-plates mold / Cold runner No.21063-B

Display diagram

Medical Instrument PN-1691 (1*4) / Two-plates mold / Cold runner No.21063-B Images
